Ingersoll Rand 1” Square Drive, 6” Ext Anvil 285B-6 1475 ft-lbs Heavy Duty D-Handle Air Impact Wrench. Actuation/Throttle Type/Switch Type: Inside Trigger, Feather-Touch Trigger Air Consumption @ Load (cfm): 61 cfm Air Consumption @ Load (l/min): 1727
The Ingersoll Rand 1” Square Drive, 6” Ext Anvil 285B-6 1475 ft-lbs Heavy Duty D-Handle Air Impact Wrench combines exceptional power, control and durability. It delivers 1770 ft-lb of maximum torque @ 120 psi, with 5,250RPM free speed and a high-efficiency, 6-vane motor. The swept-back 285B handle provides excellent maneuverability. The 285B 6-inch extended anvil makes changing tires and deeper fastening will be a breeze.
The rocking dog’s combination of high inertia and low BPM means this tool can deliver a powerful blow with little air, giving you all the power you want without having to overextend yourself. Designed for the professional with over 1770 ft-lbs of torque for the toughest applications. Built with a steel hammer case and metal housing, this wrench can withstand repeated drops and harsh weather conditions. Durable and Resistant: Phenolic 6-vane motor resist harsh environments for less downtime on the job. A protective rubber boot shields the tool from exterior damage. With multiple retention methods and a 6-inch extended anvil you access hard-to-reach spaces, while maintaining a strong connection to the socket. Feather Touch trigger and 3 position power regulator in both forward and reverse. Ergonomic swept-back handle provides excellent maneuverability. The impact wrench has a free speed of 5,250RPM. Optimized for the vehicle repair industry, heavy trucks, tire lanes, and MRO, as well as general industrial and facility maintenance.
The Ingersoll Rand 1” Square Drive, 6” Ext Anvil 285B-6 1475 ft-lbs Heavy Duty D-Handle Air Impact Wrench is backed by a 1-year warranty for peace of mind.
| Part Number | 285B-6 |
|---|---|
| Actuation/Throttle/Switch | Feather-Touch Trigger, Inside Trigger |
| Air Cons. @ Load (cfm) | 61 cfm |
| Air Cons. @ Load (l/min) | 1727 l/min |
| Air Inlet | 1/2'' NPT |
| Air Pressure (PSI) | 120 PSI |
| Anvil Length | 6'' Extended |
| Average Air Cons. (cfm) | 10 cfm |
| Average Air Cons. (l/min) | 283 l/min |
| Blows per Min | 830 BPM |
| Color | Grey |
| Configuration/Handle Type | D-Handle |
| Drive Size | 1'' |
| Drive Type | Square |
| Duty Rating | Heavy Duty |
| End Plates | Cast Iron |
| Exhaust Location | Bottom |
| Hammer Case | Aluminum |
| Housing Material | Aluminum Core with Composite Sleeve |
| Impact Mechanism | Rocking Dog |
| Max Bolt Diameter | 1-1/4'' |
| Max Free Speed (rpm) | 5250RPM |
| Max torque | 1770 ft-lbs / 21242 in-lbs / 2400 Nm |
| Min. Hose Size | 3/4'' |
| Motor | Non-Biased |
| Number of Power Settings | 3 |
| Power Source | Air Powered |
| Product Height | 7.18'' / 182mm |
| Product Length | 20.43'' / 519mm |
| Product Weight | 27.8lbs / 12.61kg |
| Product Width | 7.94'' / 202mm |
| Rec. Forward Torque Range | 120-1080 ft-lbs / 1443-12957 in-lbs / 163-1464 Nm |
| Retainer Type | Friction Ring and Thru-hole |
| Side to Center Distance(in) | 4.1'' / 104mm |
| Sound Pressure/Power Db(A) | 107/118 |
| Speed Setting | Variable Speed |
| Standards/Certifications | Cagi B186, Iso 11148-6, Iso 15744, Iso 28927-2 |
| Tool Type | Full-size |
| UPC | 663023047362 |
| Vanes | 6 |
| Vibration Level (m/s2) | 13.3m/s2 |
| Vibration Uncertainy K* (m/s2) | 2.1m/s2 |
| Warranty | 1-year |
